UniFi 6 Lite Access Point
By Brian Long
The UniFi 6 Lite (U6-Lite) is Ubiquiti’s entry-level Wi-Fi 6 access point, offering a cost-effective solution for upgrading to the latest wireless standard. With its sleek, compact design, the U6-Lite can be easily mounted on a ceiling or wall, blending seamlessly into any environment.
Featuring 2x2 MIMO on both the 2.4 GHz and 5 GHz bands, the U6-Lite delivers an aggregate data rate of up to 1.5 Gbps, providing reliable and fast wireless connectivity for up to 300 concurrent clients. Its support for the latest Wi-Fi 6 technologies, including OFDMA and MU-MIMO, ensures efficient spectrum utilization and reduced latency, making it ideal for high-density deployments.
The U6-Lite is powered via 802.3af PoE, simplifying installation by eliminating the need for separate power cables. It is managed through the intuitive UniFi Network Controller, allowing for seamless integration with existing UniFi networks and centralized management of multiple devices.
- Compact, low-profile design for discreet installation
- Dual-band Wi-Fi 6 technology with 2x2 MIMO
- Aggregate data rate up to 1.5 Gbps
- Supports up to 300 concurrent clients
- Powered via 802.3af PoE for simplified installation
- Managed through UniFi Network Controller for centralized management
| Specification | Value |
|---|---|
| Dimensions | Ø160 x 33 mm (Ø6.3 x 1.3") |
| Weight | Without mount: 300 g (10.6 oz) |
| Networking Interface | (1) GbE RJ45 port |
| Max. Power Consumption | 12W |
| Power Method | 802.3af PoE |
| Max. TX Power | 2.4 GHz: 23 dBm5 GHz: 23 dBm |
| Antenna Gain | 2.4 GHz: 2.8 dBi5 GHz: 3 dBi |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
- Datasheet - Comprehensive technical specifications and features.
- Installation Guide - Step-by-step instructions for setup and installation.
