UniFi 6 Pro Access Point
By Brian Long
The UniFi 6 Pro (U6-Pro) is engineered to provide superior Wi-Fi coverage and performance, making it an ideal choice for both residential and commercial settings. With support for the latest Wi-Fi 6 (802.11ax) technology, it offers increased capacity, efficiency, and reliability for today’s demanding wireless applications.
Featuring 4x4 MU-MIMO on the 5 GHz band and 2x2 MU-MIMO on the 2.4 GHz band, the U6-Pro delivers an aggregate data rate of up to 5.3 Gbps, ensuring high-speed connectivity for multiple devices simultaneously. Its sleek, low-profile design allows for seamless integration into any environment, and it can be easily mounted on walls or ceilings.
The U6-Pro is powered via Power over Ethernet (PoE), simplifying installation by eliminating the need for separate power cables. It integrates seamlessly with the UniFi Network Controller, providing centralized management and monitoring of all network devices.
- Dual-band Wi-Fi 6 technology with 4x4 MU-MIMO on 5 GHz and 2x2 MU-MIMO on 2.4 GHz
- Aggregate data rate up to 5.3 Gbps
- Supports over 350 concurrent clients
- Powered via PoE for simplified installation
- Sleek design suitable for wall or ceiling mounting
- Managed through UniFi Network Controller
| Specification | Value |
|---|---|
| Dimensions | Ø197 x 35 mm (Ø7.8 x 1.4") |
| Weight | Without mount: 580 g (1.3 lb) |
| Networking Interface | (1) GbE RJ45 port |
| Max. Power Consumption | 13W |
| Max. TX Power | 2.4 GHz: 22 dBm5 GHz: 26 dBm |
| Antenna Gain | 2.4 GHz: 4 dBi5 GHz: 6 dBi |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Concurrent Clients | 350+ |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
- Datasheet - Comprehensive technical specifications and features.
- Installation Guide - Step-by-step instructions for setup and installation.
For quotes and expert services, contact Synapses Technologies—your trusted partner for UniFi solutions, installation, and project management.
