UniFi U7 Pro Wall Access Point
By Brian Long
The UniFi U7 Pro Wall is Ubiquiti’s latest wall-mounted Wi-Fi 7 access point, engineered to provide superior wireless performance in modern environments. With support for the 6 GHz band, it offers interference-free connectivity, ensuring optimal performance for contemporary applications.
Equipped with 6 spatial streams, the U7 Pro Wall delivers impressive data rates across its tri-band configuration:
- 2.4 GHz: Up to 688 Mbps
- 5 GHz: Up to 4.3 Gbps
- 6 GHz: Up to 5.7 Gbps
This ensures high-speed connectivity for a multitude of devices, supporting over 300 concurrent clients, making it ideal for large-scale deployments.
The U7 Pro Wall is powered via PoE+, simplifying installation by utilizing existing network infrastructure. Its sleek design allows for seamless integration into various environments, with flexible mounting options for wall installations.
Managed through the intuitive UniFi Network Controller, the U7 Pro Wall offers centralized management and monitoring of all network devices, ensuring streamlined network administration.
- Tri-band Wi-Fi 7 technology with 6 spatial streams
- Supports 2.4 GHz, 5 GHz, and 6 GHz bands for interference-free connectivity
- Aggregate data rate up to 10.7 Gbps
- Supports over 300 concurrent clients
- Powered via PoE+ for simplified installation
- Flexible mounting options for wall installations
- Managed through UniFi Network Controller
| Specification | Value |
|---|---|
| Dimensions | 150 x 103 x 36 mm (5.9 x 4.1 x 1.4") |
| Weight | 580 g (1.3 lb) |
| Networking Interface | (1) 1/2.5 GbE RJ45 port |
| Max. Power Consumption | 22W |
| Max. TX Power | 2.4 GHz: 22 dBm5 GHz: 26 dBm6 GHz: 23 dBm |
| Antenna Gain | 2.4 GHz: 4 dBi5 GHz: 5 dBi6 GHz: 6 dBi |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax/be (Wi-Fi 6/6E/7) |
| Concurrent Clients | 300+ |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
- Datasheet - Comprehensive technical specifications and features.
- Installation Guide - Step-by-step instructions for setup and installation.
For quotes and expert services, contact Synapses Technologies—your trusted partner for UniFi solutions, installation, and project management.
