UniFi Standard 48 PoE Switch
By Brian Long
The UniFi Standard 48 PoE Switch (USW-48-POE) is a high-performance, fanless switch designed to provide robust networking solutions for medium to large-sized businesses. With its 48 Gigabit Ethernet ports, including 32 PoE+ ports, and 4 SFP ports, it ensures seamless connectivity and power delivery to a variety of devices such as access points, IP cameras, and VoIP phones. :contentReference[oaicite:0]{index=0}
This switch boasts a total non-blocking throughput of 52 Gbps and a switching capacity of 104 Gbps, ensuring efficient data transfer across your network. Its fanless, silent cooling design makes it ideal for noise-sensitive environments, while the refined rack-mountable industrial design allows for easy integration into existing network setups. :contentReference[oaicite:1]{index=1}
With a total available PoE of 195W and a maximum PoE wattage per port of 32W, the USW-48-POE can effectively power multiple devices simultaneously. The switch also features a 1.3" touchscreen LCM display for easy monitoring and management. :contentReference[oaicite:2]{index=2}
- 48 Gigabit Ethernet ports
- 32 PoE+ ports with 195W total PoE availability
- 4 SFP ports for fiber uplink connectivity
- Fanless, silent cooling design
- 1.3" touchscreen LCM display for easy monitoring
- Rack-mountable industrial design
Specification | Value |
---|---|
Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
Weight | 4.5 kg (10 lb) without mounting brackets |
Total Non-Blocking Throughput | 52 Gbps |
Switching Capacity | 104 Gbps |
Forwarding Rate | 77.38 Mpps |
Max. Power Consumption | 45W (Excluding PoE output) |
Total Available PoE | 195W |
Max. PoE Wattage per Port | 32W |
Operating Temperature | -5 to 40° C (23 to 104° F) |
Operating Humidity | 10 to 90% noncondensing |
Certifications | CE, FCC, IC |
- Datasheet - Comprehensive technical specifications and features.
- Installation Guide - Step-by-step instructions for setup and installation.
