UniFi Gateway Lite
By Brian Long
The UniFi Gateway Lite (UXG-Lite) is a compact and powerful gateway designed to deliver advanced routing and security features for small to medium-sized networks. With its dual-core ARM Cortex-A53 processor running at 1 GHz and 1 GB DDR3L memory, it ensures efficient network performance and management.
This gateway features one Gigabit Ethernet WAN port and one Gigabit Ethernet LAN port, providing seamless connectivity for your network devices. Its compact design and USB-C power method make it easy to integrate into various network setups.
The UXG-Lite supports a full suite of advanced routing and security functionalities, including application-aware firewall rules, signature-based IPS/IDS threat detection, content filtering, and VLAN-based traffic segmentation. It also offers WiFi Quality of Service (QoS) when paired with UniFi Access Points, ensuring optimal performance for your wireless devices.
With an IDS/IPS throughput of up to 1 Gbps, the UniFi Gateway Lite is capable of handling high-speed internet connections while maintaining robust security measures. Its fanless design ensures silent operation, making it suitable for noise-sensitive environments.
- Dual-core ARM Cortex-A53 processor at 1 GHz
- 1 GB DDR3L memory
- 1 Gigabit Ethernet WAN port
- 1 Gigabit Ethernet LAN port
- USB-C powered (adapter included)
- Advanced routing and security features
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- WiFi QoS with UniFi Access Points
- Compact and fanless design for silent operation
| Specification | Value |
|---|---|
| Dimensions | 98 x 98 x 30 mm (3.9 x 3.9 x 1.2") |
| Weight | 320 g (11.3 oz) |
| Enclosure Material | Polycarbonate |
| Processor | Dual-core ARM Cortex-A53 at 1 GHz |
| Memory | 1 GB DDR3L |
| Management Interface | Ethernet, Bluetooth 5.1 |
| Networking Interfaces | 1x GbE RJ45 WAN port, 1x GbE RJ45 LAN port |
| IDS/IPS Throughput | 1 Gbps* |
| Power Method | USB Type-C (5V/3A) |
| Max. Power Consumption | 3.83W |
| Operating Temperature | -10 to 40° C (14 to 104° F) |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| *Measured with iPerf3 on DHCP WAN. Performance may be reduced with PPPoE depending on ISP implementation. |
- Datasheet - Comprehensive technical specifications and features.
- Installation Guide - Step-by-step instructions for setup and installation.
For quotes and expert services, contact Synapses Technologies—your trusted partner for UniFi solutions, installation, and project management.
